TECHNICAL SPECIFICATIONS: PAGE 101 - 108
1-877-765-9565
WWW.POLYLOK.COMRISER & PIPE ADAPTER RINGS
RISER-TO-RISER ADAPTERS
Polylok’s 20” & 24” riser-to-riser adapter allows
ANY
other manufacturer’s tanks, risers, corrugated or
dual wall pipe to be converted to Polylok’s risers. Simply screw the adapter with a butyl seal onto the
appropriate riser, and that’s it! You can now use any 20” or 24” Polylok riser.
12” & 20”/24” POLYLOK RISER ADAPTER RINGS
Polylok manufactures the only adapter ring on the market that accepts
20” or 24” Polylok risers. Our adapter ring is ideal for retrofitting existing
septic tanks and can be secured with ease. Our adapter rings are made
of virgin high density polyethylene. Polylok now offers an adapter ring
for our 12”x6” risers.
FEATURES
• Adapter ring accepts either 20'' or 24'' Polylok risers
• Covers up to 25'' square opening
• Perfect for retrofitting onto existing tanks
• Only need to inventory one adapter ring
• Save time and money with easy installation
Accepts 20”or 24” Risers
3009-AR
18” Pipe Adapter Ring
3007-ARC
12” Pipe & Riser Adapter Rings
3017-ARC (Pipe Ring)
3017-AR12 (Riser Ring)
24” Pipe Adapter Ring
3009-ARC
20” Riser-to-Riser Adapter
3009-RTR20
24” Riser-to-Riser Adapter
3009-RTR24
24" PIPE RING / TANK RING
Polylok's 24" pipe ring can be cast into a concrete slab up to 6", or fastened
to Polylok 24" risers, 24" riser pans, 24" riser adapter ring, or 24"
riser-to-riser adapter ring. The 24" pipe ring is heavy duty, and allows 24"
corrugated, 24" PVC ribbed, and 24" smooth wall pipe to be attached by
using stainless steel screws and expanding foam.
Optional Installation Kit
3009-KIT
12”, 18” & 24” PIPE ADAPTER RINGS
24” Pipe Ring / Tank Ring
3008-CPA / 3008-CPA-T
