TECHNICAL SPECIFICATIONS: PAGE 145
1-877-765-9565
WWW.POLYLOK.COMCUSTOM & LOW PROFILE EXTERNAL FILTER BASINS
LOW PROFILE EXTERNAL FILTER BASIN
Polylok’s Low Profile External Filter Basin is ideal
for those situations where space limitations are a
factor. The filter/basin combination uses the Best
Technology GF-10 filter with a 2,500 GPD capacity,
making it suitable for a wide range of commercial
applications. The Best GF-10 filter ’s multiple
filtration combinations make this external basin /
filter unit suitable for all septic tanks, grease traps
or dog kennel applications.
PART NUMBERS
• 3008-LPFB8 (1/8” filtration)
• 3008-LPFB16 (1/16” filtration)
• 3008-LPFB32 (1/32” filtration)
Sump / Ejector Pump
Can be installed with any
Polylok, Zabel or Best Filter
Basin Base
24” x 14”
Standard Domed Cover
3008-RC
Optional SmartFilter®
alarm and switch
GF-10 Effluent Filter
Optional Handle
CUSTOM BASINS FOR FILTERS & PUMPS
No other company offers the same flexibility and
variety of components as Polylok. We are able
to build to your
CUSTOM
engineered specifications.
You select your desired height, pump and/or filter
size. (Not recommend for deep installations.)
FEATURES
• Made of high density, non-corrosive polyethylene plastic
(HDPE) with the highest UV protection available
• Accepts all 2", 3", 4", SDR 35, SCH 40 & corrugated pipe
• Includes 2 grommets for filter applications or 3 grommets
for pump applications
• Watertight and airtight
• All riser basins, risers and covers include watertight gaskets
• Available in 38", 44", 50", 56" or 62" heights and 24” diameter
• Residential, commercial and pressure filters available
• Pumps or filters are additional
• Comes standard with a 24” domed cover
• Optional heavy duty and flat covers are also available
