PL-68 EFFLUENT FILTER & TEE
6 TECHNICAL SPECIFICATIONS: PAGE 82 & 83
PL-68 EFFLUENT FILTER & TEE
The PL-68 is much more than just an effluent filter. The housing can also be used as an inlet baffle (tee)
or with any 4” outlet septic tank filter. The housing is designed to accept Polylok’s snap in gas deflector
to deflect gas bubbles away from the tee and to keep the solids in the tank. The PL-68 is ideal for
residential waste flows up to 800 GPD.
Pipe Extender
4” SDR 35
to 4” SDR 35
Concrete Baffle
Filter
Gaskets
Extend & Lok™
Easily installs
into existing tanks
Pipe Adapter
4” SCH 40
to SDR 35
PL-68
Gas
Deflector
Pipe Adapter
4” SCH 40
to 110mm Pipe
Filtration
Gallons Per Day (GPD)
Linear feet of filtration
1/16”
800
68
SPECIFICATIONS
• Accepts 3/4” PVC as an extension handle
• Easy installation: filter locks in any 360º position
• Tee accepts 3” and 4” SCH 40 & SDR 35 pipe
• Gasket prevents bypass
• Tee extensions available to lengthen to 16” or 18”
• Filter fits any 4” tee on the market
• Tee accepts optional PL-68 gas deflector
FEATURES
Extends life of leaching fields
Keeps solids in septic tank
Reduces TSS & CBOD5
Residential applications
BENEFITS
PL-68 filter & tee
PL-68 filter only
PL-68 tee only
30130-68H
30130
30142-68
PART NUMBERS
Visit our website for more information including technical
drawings, installation & maintenance instructions, installation
photos and videos.
ZABEL COMPARABLE FILTER: A1800
