Polylok Product Catalog

7 / 186

1-877-765-9565
7 TECHNICAL SPECIFICATIONS: PAGE 84
Septic Tank Risers
Easily bring your septic
tank to grade
PL-122 EFFLUENT FILTER
The PL-122 is the original Polylok filter. It was the first filter on the market with an automatic shut-off
ball installed with every filter. When the filter is removed for regular servicing, the ball will float up and
prevent any solids from leaving the tank. Our patented design cannot be duplicated. The PL-122 is ideal
for residential waste flows up to 3,000 gallons per day (GPD).
Filtration
Gallons Per Day (GPD)
Linear feet of filtration
1/16”
3,000
122
SPECIFICATIONS
• Accepts 1/2” SCH 40 pipe extension handle
• Optional SmartFilter® alarm and switch
• Filter housing available with choice of pipe adapter or
filter ready wall adapter
• Up to three can be stacked for increased GPD
• Shut-off ball acts as a gas deflector
FEATURES
Extends life of leaching fields
Keeps solids in septic tank
Reduces TSS & CBOD5
Installs in multiples for larger flows
Residential & commercial applications
BENEFITS
PL-122 filter & housing
PL-122 pipe adapter
PL-122 filter ready seal adapter
PATENTS • 5,871,640 • 6,015,488
PART NUMBERS
Visit our website for more information including technical
drawings, installation & maintenance instructions, installation
photos and videos.
3014
30145
30144
Filter Ready Adapter
Connects filter housing to
septic tank wall
SmartFilter® alarm and switch
Visual and audible notification
of impending filter and tank servicing
Twist & Lok Filter Handle
Accepts 1/2”
SCH 40 pipe
PL-122 EFFLUENT FILTER
ZABEL COMPARABLE FILTER: A100
