13 TECHNICAL SPECIFICATIONS: PAGE 90 - 92
A100/A300/A600 EFFLUENT FILTERS
A100 - 8” & 12” SERIES
A100 Filter 1/16” Filtration (8” and 12” Diameter)
This filter is ideal for larger homes, multi-family homes, or light commercial settings where increased
flows or higher quality effluent is required. The A100-8 series is sized to handle flow rates from 1200
to 2400 GPD and is available in three different lengths. The A100-12 series, installed in more locations
than any other filter on the market, is sized to handle flow rates from 3000 to 6000 GPD. The A100-12
series can be used in almost any application. Independent research has shown the A100-12 series
decreases TSS by 50-90% and CBOD5 by 20-40%. With 1/16” filtration, the A100-8 series filter is
available in 18”, 26” and 32” lengths. The A100-12 series filter is available in 20”, 28” and 36” lengths.
A300 - 8” & 12” SERIES
A300 Filter 1/32” Filtration (8” and 12” Diameter)
The finer 1/32” level of filtration achieved with the A300-8 filter makes this the perfect effluent filter for
small grease trap applications, dog kennels, laundromats, and other applications where fine suspended
solids are present. The A300-8 series offers flow rates of 1200-2400 GPD. The A300-12 series provides
1/32” filtration and has been shown to reduce FOG by as much as 50-98%. The A300-12 series offers
flow rates of 3000-6000 GPD. The A300-12 is also used for onsite wastewater systems which require a
finer level of TSS removal. The A300-8 series filter is available in 18”, 26” and 32” lengths. The A300-12
series filter is available in 20”, 28” and 36” lengths.
A600 - 8” & 12” SERIES
A600 Filter 1/64” Filtration (8” and 12” Diameter)
The A600 is ideal for specialty applications where very fine filtration is required, and low flows are
expected. Due to fine, 1/64” level filtration, the A600 is recommended to be used with a SmartFilter®
switch and alarm. The SmartFilter® switch provides notification of required filter servicing through the
use of both an audible and visual alarm. A minimum of a 3” drop is required in the tank for proper
SmartFilter® operation. The A600-8 series filter is available in 18”, 26” and 32” lengths. The A600-12
series is available in 20”, 28” and 36” lengths.
Filtration
Gallons Per Day (GPD)
1/16”
1,500 - 6,300
SPECIFICATIONS
Filtration
Gallons Per Day (GPD)
1/32”
1,200 - 5,700
SPECIFICATIONS
Filtration
Gallons Per Day (GPD)
1/64”
1,000 - 4,400
SPECIFICATIONS
APPLICATIONS
• Residential
• Multi-Family
APPLICATIONS
• Residential
• Multi-Family
• Grease Traps
APPLICATIONS
• Residential
• Multi-Family
• Grease Traps
