14 TECHNICAL SPECIFICATIONS: PAGE 90 - 92
A100/A300/A600 EFFLUENT FILTERS
12x20
without Shut-Off Ball
12x20
with Shut-Off Ball
A100 / A300 / A600 - 12X20 SERIES
The original Zabel® disc dam filter was patented in 1959. The 12” Series filters have been filtering
wastewater longer than any other filter in the wastewater industry. In 2000, Zabel made the original even
better by introducing a complete redesign of the series with more great features and finer levels of
filtration. In 2006, Polylok, Inc. redesigned the A100/300/600-12X20 merging the best of the Polylok
line with the best features of the Zabel line. This new innovative design is available with or without
our patented red shut-off ball.
Filtration
Gallons Per Day (GPD)
1/16” 1/32” 1/64”
3,000 2,600 2,200
SPECIFICATIONS
Polylok’s redesign of the Zabel filter includes ribbing on the
outside for additional strength. The filter is much lighter in
weight, and offers an improved latching mechanism to prevent
the filter from floating. You will also see guide rails that
simplify removal and replacement during cleaning. The central
support rod has been modified on all Zabel A100, A300, and
A600 models to provide greater strength and durability. The
new central support system is thicker than the original. It was
tested up to 1,200 lbs!
FEATURES
• Available level of filtration:
A100 1/16", A300 1/32" & A600 1/64"
• Flow rates of 3000, 2600 & 2200 GPD
• Optional SmartFilter® switch and alarm
• Versa-Case with built in reducer/adapter and allows solvent
welding to either 4" or 6" SCH 40 pipe
• Independent research has shown the A100-12x20 decreases
TSS by 50-90% and CBOD5 by 20-40%
• Optional gas deflector & automatic shut-off ball available
on the 12”x20”
APPLICATIONS
• Residential
• Multi-Family
• Grease Traps (A300)
Extend & Lok™
Easily installs
into existing tanks
SmartFilter® alarm and switch
Visual and audible notification
of impending filter and tank servicing
Filter Handle
Accepts 1”
SCH 40 pipe
Prep & Clean™
Natural bacteria designed to clean filters
when a hose is not readily available
A100 A300 A600
