12" x 12"
SQUARE COVER
PDB-12C
32 TECHNICAL SPECIFICATIONS: PAGE 134 - 136
1-877-765-9565
SQUARE CATCH BASINS & D-BOX
9” x 9” & 12” x 12” CATCH BASINS
Offered in two sizes, Polylok manufactures the
most versatile catch basin on the market. The
basin comes complete with either a black or green
grate, and two seals that accept 2”, 3”, 4” and
4” corrugated pipe. You can choose your inlet and
outlet heights, and it can accept one inlet and up
to three outlets. The 12” x 12” catch basin accepts
4” and 6” pipe.
FEATURES
• Available in 9” x 9” and 12” x 12” configurations
• Precut with two inlet/outlet holes
• 12” x 12” catch basins accept 6” pipe (sold separately)
• Seals accept 2”, 3”, 4” and 4” corrugated pipe
• Cast iron grates available
• Designed to withstand normal abuse in landscaping
applications
• Pick the color grate to suit your design needs.
(black, green, or cast iron)
• Kit comes with box, grate, two 4” seals, nuts, and screws
GRATE OPTIONS:
• PDB-9G-BK (9” black plastic grate)
• PDB-9G-GN (9” green plastic grate)
• PDB-9GM (9” cast iron grate)
• PDB-12G-BK (12” black plastic grate)
• PDB-12G-GN (12” green plastic grate)
• PDB-12GM (12” cast iron grate)
• PDB-12AG-BK (12” black atrium grate)
• PDB-12AG-GN (12” green atrium grate)
12” SQUARE D-BOX
The 12" Polylok square D-Box comes factory precut
with one inlet and three outlets. Four seal assemblies
are provided with each unit and will accept 2”, 3”,
and 4” pipe. Optional 6” seals are also available
for applications demanding 6” pipe. Polylok’s 12”
square D-Box has a five gallon capacity and is
designed to withstand normal abuse in landscaping
applications
FEATURES
• 12” x 12” configuration
• Precut with two inlet/outlet holes
• 12” x 12” D-Box accept 6” pipe
• Seals accept 2”, 3”, 4” and corrugated pipe
• Accepts 12” x 12” square riser
• Designed to withstand normal abuse in landscaping
applications
2 Sides 2 Sides
2 Sides 2 Sides
9” x 9”
PDB-9KIT (Black)
PDB-9KITG (Green)
12” x 12”
PDB-12KIT (Black)
PDB-12KITG (Green)
2 Sides 2 Sides
12” x 12”
Square D-Box
3016-DB12
12” x 12”
Square Riser
PDB-12R
4” D-Box
Seal & Nut
3001-SN
6” D-Box
Seal & Nut
3001-6 / 3001-N6
