35 TECHNICAL SPECIFICATIONS: PAGE 137 - 141
DUCTILE GRATES FOR HD TRENCH/CHANNEL DRAIN
Ductile Grate Mounting Hardware
Each channel has four (4) drainage ports
that will accept 3” or 4” SCHD 40, or
4” SDR 35 pipe.
2x4s can be fastened to the
underside to provide a wider footing.
Outside holes accept #4
rebar for fast positioning.
DUCTILE GRATES FOR POLYLOK HEAVY
DUTY TRENCH/CHANNEL DRAINS
Polylok drains offer homeowners, architects,
engineers, contractors and storm water managers
a variety of superior surface drains for a myriad of
applications. No matter what the situation requires,
from residential to heavy industrial applications, our
quality is unmatched. Polylok drains are engineered
for simple one-step installations, minimizing
contractor costs for installation. Polylok drains meet
or exceed the ADA American Disabilities Act of
1990; Section 4.5.4. Polylok drains are a practical
and cost-effective solution where runoff needs to
be controlled or captured.
FEATURES
• Comes with all stainless steel hardware
• Easily installed and removed with one bolt
• 47 sq. in. of open area
• Rust resistant
• Load Class C
• Application: Heavy Duty/Commercial
• Application proof load: 310 psi
• Typical application standard: A-A6005
FEATURES & BENEFITS FOR EASY INSTALLATION
Ductile Tee Ductile 90°
