ORIFICE DIFFUSER
Polylok’s orifice diffuser offers advancements in effluent distribution you will not see in other pressure
dosing systems. Our patented design includes an impeller that directs wastewater from the discharge
piping in a 360º manner. This optimizes the leaching fields and protects the soils around the piping
from unnecessary erosion.
FEATURES
• Fits securely onto either ¾”-1” pipe or 1¼”-2” pipe
• Constructed of engineered resin
• Provides a tight fit which prevents slippage once installed
• Slotted design prevents plugging of discharge openings
with surrounding soil
• Can be installed with discharge openings facing up or down
• 360º equal flow distribution with impeller
OUR ORIFICE DIFFUSERS
ACCOMMODATE TWO SIZES
• 3081 (¾” - 1” pipe)
• 3080 (1¼” - 2” pipe)
Patented impeller design
PATENT • 7,387,468 B2
HYDROSHIELD
The hydroshield is a practical solution for protecting pressure distribution field pipes from external
contamination. The unique, patent pending design offers a wide range of benefits and will accommodate
3 sizes of pipe.
FEATURES
• 3 sizes in 1
• 360º equal distribution
• Reduces inventory requirements
• The hemispherical shape and large surface area allows
effluent to disperse more evenly
• The easy, snap on installation provides a firm lateral grip
to the pipe and prevents movement of the hydroshield
during backfilling
• The stackable design reduces storage space requirements
and shipping costs
OUR HYDROSHIELDS EACH
ACCOMMODATE THREE SIZES
• 3082 (Green 1”, 1.25” & 1.5” pipe)
• 3082-2 (Yellow 1”, 1.5” & 2” pipe)
39 TECHNICAL SPECIFICATIONS: PAGE 143
