Polylok Product Catalog

59 / 186

1-877-765-9565
59 TECHNICAL SPECIFICATIONS: PAGE 161
BAFFLE & GAS DEFLECTOR
TOP VIEW
Baffle Ready
cast in
Polylok Seal
Stainless steel nails drive in, screw out. See PAGE 17: for more Baffle & Gas Deflector options.
BAFFLE TECHNOLOGY FOR THE
SEPTIC SYSTEM
The original Polylok baffle deflects suspended solids
and prevents them from exiting the septic tank.
Installs in minutes when using the Polylok Baffle
Ready Seal. At 38” in length, it can be cut to different
heights to eliminate waste. Don’t be fooled by
imitations!
FAST INSTALLATION
• Quickly connects in under 30 seconds
• No drilling necessary
• No tracks
• Ideal for inlet and outlet
HIGHEST QUALITY
• Plastic baffle will not deteriorate under constant
attack from gases and chemicals in the septic tank
MOST EFFECTIVE
• No slippage - it’s securely fastened
• Meets ASTM 1227
BENEFITS
• Gas deflector snaps onto baffle
• Deflects suspended solids and prevents them
from exiting the septic tank
• Increases quality of the effluent
• Reduces clogging at the soil-stone interface
• Easy installation, no parts to maintain or clean
• Economical, saves time
PART NUMBERS
• 3015 (Baffle)
• 3023 (Gas deflector)
• 3040 (Stainless steel screws for baffle)
NO DRILLING NECESSARY!
1. Attach baffle ready Polylok seal onto the
mandrel.
2. Pour concrete.
3. Attach baffle to Polylok’s seal with stainless
steel nails.
Baffle shown with
optional gas deflector.
